Section 7: TSP command reference Model 2657A High Power System SourceMeter® Instrument Reference Manual
7-282 2657A-901-01 Rev. B/December 2012
status.operation.instrument.trigger_blender.*
This attribute contains the operation status trigger blender summary register set.
Type TSP-Link accessible Affected by Where saved Default value
Attribute - - - - - - - -
.condition (R) Yes Not applicable Not saved Not applicable
.enable (RW) Yes Status reset Not saved 0
.event (R) Yes Status reset Not saved 0
.ntr (RW) Yes Status reset Not saved 0
.ptr (RW) Yes Status reset Not saved 1024 (All bits set)
Usage
operationRegister = status.operation.instrument.trigger_blender.condition
operationRegister = status.operation.instrument.trigger_blender.enable
operationRegister = status.operation.instrument.trigger_blender.event
operationRegister = status.operation.instrument.trigger_blender.ntr
operationRegister = status.operation.instrument.trigger_blender.ptr
status.operation.instrument.trigger_blender.enable = operationRegister
status.operation.instrument.trigger_blender.ntr = operationRegister
status.operation.instrument.trigger_blender.ptr = operationRegister
operationRegister
The status of the operation status trigger blender summary register; a zero (0)
indicates no bits set (also send 0 to clear all bits); the only valid value other than 0 is
1024
Details
These attributes are used to read or write to the operation status trigger blender summary registers. Reading a
status register returns a value. The binary equivalent of the returned value indicates which register bits are set.
The least significant bit of the binary number is bit B0, and the most significant bit is bit B15.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set contents
(on
page E-1) and Enable and transition registers
(on page E-19). The individual bits of this register are defined in
the following table.
Bit Value Description
B0-B9 Not used Not applicable.
B10
status.operation.instrument.trigger_blender.TRIGGER_OVERRUN
status.operation.instrument.trigger_blender.TRGOVR
Set bit indicates one
or more enabled bits
for operation status
trigger blender
overrun register is
set.
Bit B10 decimal
value: 1,024
Binary value:
0100 0000 0000
B11-B15 Not used Not applicable.
