Model 2657A High Power System SourceMeter® Instrument Reference Manual Section 7: TSP command reference
2657A-901-01 Rev. B/December 2012 7-113
Details
This attribute does not indicate the actual setting currently in effect. Use the lan.status.duplex attribute to
determine the present operating state of the LAN.
Also see
lan.restoredefaults() (on page 7-118)
lan.config.gateway
This attribute contains the LAN default gateway address.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes LAN restore defaults Nonvolatile memory "0.0.0.0"
Usage
gatewayAddress = lan.config.gateway
lan.config.gateway = gatewayAddress
gatewayAddress
LAN default gateway address; must be a string specifying the default
gateway’s IP address in dotted decimal notation
Details
This attribute specifies the default gateway IP address to use when manual or DLLA configuration methods are
used to configure the LAN. If DHCP is enabled, this setting is ignored.
This attribute does not indicate the actual setting that is presently in effect. Use the lan.status.gateway
attribute to determine the present operating state of the LAN.
The IP address must be formatted in four groups of numbers, each separated by a decimal.
Example
print(lan.config.gateway)
Outputs the default gateway address. For example,
you might see the output:
192.168.0.1
Also see
lan.restoredefaults() (on page 7-118)
lan.status.gateway
(on page 7-120)
lan.config.ipaddress
This attribute specifies the LAN IP address.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes LAN restore defaults Nonvolatile memory "192.168.0.2"
