Keithley 2657A User Manual

Model 2657A High Power System SourceMeter® Instrument Reference Manual Section 7: TSP command reference
2657A-901-01 Rev. B/December 2012 7-231
Example
smua.trigger.endpulse.action =
smua.SOURCE_IDLE
smua.trigger.endpulse.stimulus =
trigger.timer[1].EVENT_ID
Configure the end pulse action to achieve a
pulse and configure trigger timer 1 to control
the end of pulse.
Also see
Triggering (on page 3-31)
smuX.trigger.endpulse.set()
This function sets the end pulse event detector to the detected state.
Type TSP-Link accessible
Affected by Where saved Default value
Function Yes
Usage
smuX.trigger.endpulse.set()
X
Source-measure unit (SMU) channel (for example,
smua.trigger.endpulse.set() applies to SMU channel A)
Details
This function sets the end pulse event detector to the detected state.
The SMU automatically clears all the event detectors when the smuX.trigger.initiate() function is
executed. Therefore, smuX.trigger.endpulse.set() should be called after the sweep is initiated. If the
event detectors are configured to clear automatically because the smuX.trigger.autoclear attribute is set to
smuX.ENABLE, make sure that smuX.trigger.endpulse.set() is issued after the SMU has entered the
trigger layer.
Also see
smuX.trigger.autoclear (on page 7-229)
smuX.trigger.initiate()
(on page 7-234)
Triggering
(on page 3-31)
smuX.trigger.endpulse.stimulus
This attribute defines which event will cause the end pulse event detector to enter the detected state.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes SMU reset
Instrument reset
Recall setup
Not saved 0
Usage
eventID = smuX.trigger.endpulse.stimulus
smuX.trigger.endpulse.stimulus = eventID
eventID
Set to the event that triggers the end pulse action of the source
X
Source-measure unit (SMU) channel (for example,
smua.trigger.endpulse.stimulus applies to SMU channel A)
