Section 7: TSP command reference Model 2657A High Power System SourceMeter® Instrument Reference Manual

7-350 2657A-901-01 Rev. B/December 2012

Details

This number is used by the TSP-Link trigger line when it detects an input trigger.

Set the stimulus of any trigger object to the value of this constant to have the trigger object respond to trigger

events from this line.

Example

trigger.timer[1].stimulus = tsplink.trigger[2].EVENT_ID

Sets the trigger stimulus

of trigger timer 1 to the

TSP-Link trigger 2 event.

Also see

None

tsplink.trigger[N].mode

This attribute defines the trigger operation and detection mode.

Type TSP-Link accessible Affected by Where saved Default value

Attribute (RW) Yes Instrument reset

Recall setup

TSP-Link trigger N reset

Not saved 0 (tsplink.TRIG_BYPASS)

Usage

mode = tsplink.trigger[N].mode

tsplink.trigger[N].mode = mode

mode

The trigger mode

The trigger line (1 to 3)

Details

This attribute controls the mode in which the trigger event detector and the output trigger generator operate on

the given trigger line.
