Keithley 2657A User Manual

Model 2657A High Power System SourceMeter® Instrument Reference Manual Section 7: TSP command reference
2657A-901-01 Rev. B/December 2012 7-315
Bit B7 B6 B5 B4 B3 B2 B1 B0
Binary value 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1
Decimal 128 64 32 16 8 4 2 1
Weights
(2
7
) (2
6
) (2
5
) (2
4
) (2
3
) (2
2
) (2
1
) (2
0
)
Bit B15 B14 B13 B12 B11 B10 B9 B8
Binary value 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1
Decimal 32,768 16,384 8,192 4,096 2,048 1,024 512 256
Weights
(2
15
) (2
14
) (2
13
) (2
12
) (2
11
) (2
10
) (2
9
) (2
8
)
Example 1
enableRegister = status.system.NODE11 +
status.system.NODE14
status.system.enable = enableRegister
Uses constants to set bits B11 and B14
of the system summary enable register.
Example 2
-- decimal 18432 = binary 0100 1000 0000 0000
enableRegister = 18432
status.system.enable = enableRegister
Uses a decimal value to set bits B11 and
B14 of the system summary enable
register.
Also see
status.system2.* (on page 7-315)
System summary and standard event registers
(on page E-7)
status.system2.*
These attributes manage the TSP-Link
®
system summary register of the status model for nodes 15 through 28.
Type TSP-Link accessible Affected by Where saved Default value
Attribute - - - - - - - -
.condition (R) Yes Not applicable Not saved Not applicable
.enable (RW) Yes Status reset Not saved 0
.event (R) Yes Status reset Not saved 0
.ntr (RW) Yes Status reset Not saved 0
.ptr (RW) Yes Status reset Not saved 32,767 (All bits set)
Usage
enableRegister = status.system2.condition
enableRegister = status.system2.enable
enableRegister = status.system2.event
enableRegister = status.system2.ntr
enableRegister = status.system2.ptr
status.system2.enable = enableRegister
status.system2.ntr = enableRegister
status.system2.ptr = enableRegister
enableRegister
The status of the system summary 2 register; a zero (0) indicates no bits set; other
values indicate various bit settings
