Keithley 2657A User Manual

Section 7: TSP command reference Model 2657A High Power System SourceMeter® Instrument Reference Manual
7-214 2657A-901-01 Rev. B/December 2012
Details
This function generates and activates new calibration constants for the given range.
The positive and negative polarities of the source must be calibrated separately. Use a positive value for range to
calibrate the positive polarity and a negative value for range to calibrate the negative polarity. Do not use 0.0 for
a negative calibration point; 0.0 is considered to be a positive number.
Typically, the two calibration points used will be near zero for calibration point 1 and 90% of full scale for
calibration point 2. Full scale for calibration point 2 should be avoided if the source of the SMU is substantially
out of calibration.
The two reference measurements must be made with the source using the active calibration set. For example,
source a value, measure it, and do not change the active calibration set before issuing this command.
The new calibration constants are activated immediately but they are not written to nonvolatile memory. Use
smuX.cal.save() to save the new constants to nonvolatile memory.
The active calibration constants stay in effect until the instrument is power cycled or a calibration set is loaded
from nonvolatile memory with the smuX.cal.restore() function.
This function is disabled until a successful call to smuX.cal.unlock() is made.
Example
smua.source.calibratev(200, 1e-30, 1e-5, 180,
179.8)
SMU channel A calibrates the voltage
source using the following values:
calibrate the 200 V range, 1e-30 for +zero
source output value, 1e-5 for +zero DMM
measurement reading, 180 for +FS
source output value, and 179.8 for the
+FS DMM measurement reading.
Also see
Calibration (on page B-1)
smuX.cal.restore()
(on page 7-184)
smuX.cal.save()
(on page 7-185)
smuX.cal.unlock()
(on page 7-186)
smuX.measure.calibrateY()
(on page 7-196)
smuX.source.compliance
This attribute contains the state of source compliance.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (R) Yes Not applicable Not saved Not applicable
Usage
compliance = smuX.source.compliance
compliance
The state of source compliance
X
Source-measure unit (SMU) channel (for example, smua.source.compliance
applies to SMU channel A)
