Section 7: TSP command reference Model 2657A High Power System SourceMeter® Instrument Reference Manual

7-274 2657A-901-01 Rev. B/December 2012

status.operation.instrument.lan.*

This attribute contains the operation status LAN summary register set.

Type TSP-Link accessible Affected by Where saved Default value

Attribute - - - - - - - -

.condition (R) Yes Not applicable Not saved Not applicable

.enable (RW) Yes Status reset Not saved 0

.event (R) Yes Status reset Not saved 0

.ntr (RW) Yes Status reset Not saved 0

.ptr (RW) Yes Status reset Not saved 1027 (All bits set)

Usage

operationRegister = status.operation.instrument.lan.condition

operationRegister = status.operation.instrument.lan.enable

operationRegister = status.operation.instrument.lan.event

operationRegister = status.operation.instrument.lan.ntr

operationRegister = status.operation.instrument.lan.ptr

status.operation.instrument.lan.enable = operationRegister

status.operation.instrument.lan.ntr = operationRegister

status.operation.instrument.lan.ptr = operationRegister

operationRegister

The status of the operation status LAN summary register; a zero (0) indicates no

bits set (also send 0 to clear all bits); other values indicate various bit settings

Details

These attributes are used to read or write to the operation status LAN summary registers. The binary equivalent

of the value indicates which register bits are set. In the binary equivalent, the least significant bit is bit B0, and

the most significant bit is bit B15. For example, if a value of 1.02600e+03 (which is 1026) is read as the value

of the condition register, the binary equivalent is 0000 0100 0000 0010. This value indicates that bit B1 and bit

B10 are set.

B15 B14 B13 B12 B11 B10 B9 B8 B7 B6 B5 B4 B3 B2 B1 B0

** > > > > > > > > > > > > > > *

0 0 0 0 0 1 0 0 0 0 0 0 0 0 1 0

* Least significant bit

** Most significant bit
