Model 2657A High Power System SourceMeter® Instrument Reference Manual Section 7: TSP command reference
2657A-901-01 Rev. B/December 2012 7-293
status.operation.remote.*
This attribute contains the operation status remote summary register set.
Type TSP-Link accessible Affected by Where saved Default value
Attribute - - - - - - - -
.condition (R) Yes Not applicable Not saved Not applicable
.enable (RW) Yes Status reset Not saved 0
.event (R) Yes Status reset Not saved 0
.ntr (RW) Yes Status reset Not saved 0
.ptr (RW) Yes Status reset Not saved 2050 (All bits set)
Usage
operationRegister = status.operation.remote.condition
operationRegister = status.operation.remote.enable
operationRegister = status.operation.remote.event
operationRegister = status.operation.remote.ntr
operationRegister = status.operation.remote.ptr
status.operation.remote.enable = operationRegister
status.operation.remote.ntr = operationRegister
status.operation.remote.ptr = operationRegister
operationRegister
The status of the operation status remote summary register; a zero (0) indicates no
bits set (also send 0 to clear all bits); other values indicate various bit settings
Details
These attributes are used to read or write to the operation status remote summary registers. Reading a status
register returns a value. The binary equivalent of the returned value indicates which register bits are set. The
least significant bit of the binary number is bit B0, and the most significant bit is bit B15.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set contents
(on
page E-1) and Enable and transition registers
(on page E-19). The individual bits of this register are defined in
the following table.
Bit Value Description
B0 Not used Not applicable.
B1
status.operation.remote.COMMAND_AVAILABLE
status.operation.remote.CAV
Set bit indicates there is a command
available in the execution queue.
Bit B1 decimal value: 2
Binary value: 0000 0000 0000 0010
B2-B10 Not used Not applicable.
B11
status.operation.remote.PROMPTS_ENABLED
status.operation.remote.PRMPT
Set bit indicates command prompts are
enabled.
Bit B11 decimal value: 2,048
Binary value: 0000 0100 0000 0000
B12-B15 Not used Not applicable.
