Section 7: TSP command reference Model 2657A High Power System SourceMeter® Instrument Reference Manual
7-114 2657A-901-01 Rev. B/December 2012
Usage
ipAddress = lan.config.ipaddress
lan.config.ipaddress = ipAddress
ipAddress
LAN IP address; must be a string specifying the IP address in dotted decimal
notation
This attribute specifies the LAN IP address to use when the LAN is configured using the manual configuration
method. This setting is ignored when DLLA or DHCP is used.
This attribute does not indicate the actual setting that is presently in effect. Use the lan.status.ipaddress
attribute to determine the present operating state of the LAN.
Example
ipaddress = lan.config.ipaddress
Retrieves the presently set LAN IP address.
Also see
lan.restoredefaults() (on page 7-118)
lan.status.ipaddress
(on page 7-121)
lan.config.method
This attribute contains the LAN settings configuration method.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes LAN restore defaults Nonvolatile memory 0 (lan.AUTO)
Usage
method = lan.config.method
lan.config.method = method
method
The method for configuring LAN settings; it can be one of the following
values:
0 or lan.AUTO: Selects automatic sequencing of configuration methods
1 or lan.MANUAL: Use only manually specified configuration settings
Details
This attribute controls how the LAN IP address, subnet mask, default gateway address, and DNS server
addresses are determined.
When method is lan.AUTO, the instrument first attempts to configure the LAN settings using dynamic host
configuration protocol (DHCP). If DHCP fails, it tries dynamic link local addressing (DLLA). If DLLA fails, it uses
the manually specified settings.
When method is lan.MANUAL, only the manually specified settings are used. Neither DHCP nor DLLA are
attempted.
Example
print(lan.config.method)
Outputs the current method.
For example:
1.00000e+00
Also see
lan.restoredefaults() (on page 7-118)
