Section 7: TSP command reference Model 2657A High Power System SourceMeter® Instrument Reference Manual
7-304 2657A-901-01 Rev. B/December 2012
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set contents (on
page E-1) and Enable and transition registers
(on page E-19). The individual bits of this register are defined in
the following table.
Bit Value Description
B0-B7 Not used Not applicable.
B8
status.questionable.instrument.smuX.CALIBRATION
status.questionable.instrument.smuX.CAL
Set bit indicates that the
calibration constants
stored in nonvolatile
memory were corrupted
and could not be loaded
when the instrument
powered up.
Bit B8 decimal value: 256
B9
status.questionable.instrument.smuX.UNSTABLE_OUTPUT
status.questionable.instrument.smuX.UO
Set bit indicates that an
unstable output condition
was detected.
Bit B9 decimal value: 512
B10-B11 Not used Not applicable
B12
status.questionable.instrument.smuX.OVER_TEMPERATURE
status.questionable.instrument.smuX.OTEMP
Set bit indicates that an
over temperature condition
was detected.
Bit B12 decimal value:
4,096
B13-B15 Not used Not applicable.
As an example, to set bit B8 of the questionable status SMU A summary enable register, set
status.questionable.instrument.smua.enable =
status.questionable.instrument.smua.CAL.
In addition to the above constants, questionableRegister can be set to the numeric equivalent of the bit to
set. To set more than one bit of the register, set questionableRegister to the sum of their decimal weights.
For example, to set bits B8 and B9, set questionableRegister to 768 (which is the sum of 256 + 512).
Bit B7 B6 B5 B4 B3 B2 B1 B0
Binary value 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1
Decimal 128 64 32 16 8 4 2 1
Weights
(2
7
) (2
6
) (2
5
) (2
4
) (2
3
) (2
2
) (2
1
) (2
0
)
Bit B15 B14 B13 B12 B11 B10 B9 B8
Binary value 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1
Decimal 32,768 16,384 8,192 4,096 2,048 1,024 512 256
Weights
(2
15
) (2
14
) (2
13
) (2
12
) (2
11
) (2
10
) (2
9
) (2
8
)
Example
questionableRegister =
status.questionable.instrument.smua.CAL +
status.questionable.instrument.smua.UO
status.questionable.instrument.smua.enable =
questionableRegister
Uses constants to set bit B8
and bit B9 of the
questionable status SMU A
summary enable register.
Also see
Questionable Status Registers (on page E-13)
status.operation.*
(on page 7-265)
