Model 2657A High Power System SourceMeter® Instrument Reference Manual Appendix E: Status model
2657A-901-01 Rev. B/December 2012 E-27
Status configuration (enable) commands
The following commands (sent from the master node) enable the appropriate register bits for the
above example:
Node 15 status registers: The following commands enable the current limit events for SMU A of node
15:
node[15].status.measurement.current_limit.enable = 2
node[15].status.measurement.enable = 2
node[15].status.node_enable = 1
The affected status registers for the above commands are indicated by labels A, B and C (see
following figure).
Master node system summary registers: The following commands enable the required system
summary bits for node 15:
status.system2.enable = 2
status.system.enable = 1
The affected system summary registers for the above commands are indicated by labels D and E
(see following figure).
