Advanced Settings of the Color Area/Area Tool
Items Description Setting range Ref.
Advanced Color Extraction
Settings
(For color type)
Adv. Brightness Extraction
(For monochrome type)

Color type
SpeciesacolortobeextractedwiththeHSV
values (H: Hue, S: Saturation, V: Brightness).

H (Hue)
0° to 359°
(both starting point and ending
point)

S (Saturation)
0 to 255

B (Brightness)
0 to 255
4-72

Monochrome type
Speciesbrightnessvaluetobeextracted.
0 to 255
To Live Image
A color/brightness range to be extracted can be
set from the Live image of the target.
--
Fixed Reference Area
Select a condition which the matching rate of
theColorArea/Areais100%.

Based on Master (default)
Matches the area extracted from
the master image as the criteria
ofarateof100%.

Enable: Large
Matches 1/10th of the total
sensor view as the criteria of a
rateof100%.

Enable: Small
Matches 1/100th of the total
sensor view as the criteria of a
rateof100%.
4-73
Tool Name
Auser-speciedname,suchasthenameofthe
target, can be set for the tool. Tool names can
be checked on the run screen.
“5 Running” (Page 5-1)
Up to 16 characters can be set. 4-73
