Keyence IV2 Series - 4 Settings Navigator

4-1
IV2 Series User's Manual (Control Panel)
4
Settings Navigator
This chapter explains the functions and operations of the
Settings Navigator.
Settings Navigator .................................................................4-2
Basic Operation of the Settings Navigator.............................4-4
1. Image Optimization (Clearly Image a Target)....................4-8
2. Master Registration (Registering an Image as a
Reference) ...........................................................................4-18
3. Learning Settings (Setting the Judgment Method of
the Target in Learning Mode) ..............................................4-24
3. Tool Settings (Setting the Judgment Method of the
Target of Standard Mode) ...................................................4-41
4. Output Assignment (Setting Details of Outputting to
Output Line) .......................................................................4-149
(Setting the Status Conditions)
4
Settings Navigator
