4-12 Keysight E5260/E5270 User’s Guide, Edition 6
Front Panel Reference
Front Panel Key Details
Integ Selects the A/D converter (ADC) operation mode (A: auto, M: manual, or P: PLC).
Refer to Table 4-4. For the Keysight E5260, see the description of the H-SPEED.
Press the
MeasCh
key to specify the measurement channel, and press the
Integ
key
repeatedly until the desired mode appears in the Integ status area.
The setup value is effective for the channels that use the same AD type.
IntegTime
(Shift+Integ)
Displays one of the messages shown in Table 4-4. The message depends on the
AD
and
Integ
settings. For the Keysight E5260, see the description of the H-SPEED.
This function sets the number of averaging samples of the high-speed A/D converter
or the integration time of the high-resolution A/D converter. The value should be
increased for reliable and accurate measurement, or decreased for high speed
measurement. The meaning of the setting value depends on the settings of the A/D
converter type and the ADC operation mode. Refer to Table 4-4.
Press the
MeasCh
key to specify the measurement channel, and press the arrow key
to set the integration time or the number of averaging samples. Then, press the
Enter
key to make the setup effective, or press the
Exit
key to cancel changing the setup.
The setup value is effective for the channels that use the same settings of the AD
type and the ADC operation mode.
MeasRange Displays the measurement range setup menu in the Change Setup area. See
“Measurement Range Setup Menu” on page 4-31.
Single Selects the spot measurement mode and performs measurement using the channel
specified by the channel number displayed in the M-ch status area. If measurement
is in progress, stops measurement and performs spot measurement.
Note that the channel can perform measurement when its Output status is ON.
Repeat Selects the repeat measurement mode and performs measurement using the channel
specified by the channel number displayed in the M-ch status area. If measurement
is in progress, stops measurement and starts repeat measurement.
Note that the channel can perform measurement when its Output status is ON.
Abort
(Shift+Repeat)
Displays the following message. Press the arrow key to set YES, and then press the
Enter
key to stop measurement.
Abort: NO
NOTE Perform the Abort operation if the Keysight E5260/E5270 still continues the
previous operation even though the condition was changed from remote to local.
