Keysight E5260/E5270 User’s Guide, Edition 6 4-13
Front Panel Reference
Front Panel Key Details
Table 4-4 AD, Integ, and IntegTime Values
AD Integ
IntegTime message
a
and description
a. # is 1 or 2 for the 2-ch mainframe, 1, 2, ... or 8 for the 8-ch mainframe.
H-SPEED A [M-ch #] H-SPEED A N*Ref[pt], N=
Specify the N value shown in the following formula. Available values
are 1 to 1023. Initial value is 1.
Number of averaging samples = N × reference
where reference is the number of averaging samples automatically set
by the Keysight E5260/E5270 and cannot be changed.
M [M-ch #] H-SPEED M N[pt], N=
Specify the number of averaging samples (N). Available values are 1
to 1023. Initial value is 1.
P [M-ch #] H-SPEED P N*128[pt], N=
Specify the N value shown in the following formula. Available values
are 1 to 100. Initial value is 1.
Number of averaging samples = N × 128
The Keysight E5260/E5270 gets 128 samples in a power line cycle.
Hence, the N value is equal to the number of power line cycles.
H-RESOLN A [M-ch #] H-RESOLN A N*Ref[s], N=
Specify the N value shown in the following formula. Available values
are 1 to 127. Initial value is 6.
Integration time = N × reference
where reference is the integration time automatically set by the
Keysight E5270B and cannot be changed.
M [M-ch #] H-RESOLN M N*80[us], N=
Specify the N value shown in the following formula. Available values
are 1 to 127. Initial value is 3.
Integration time = N × 80 μsec
P [M-ch #] H-RESOLN P N/Freq[s], N=
Specify the N value shown in the following formula. Available values
are 1 to 100. Initial value is 1.
Integration time = N / power line frequency
The N value means the number of power line cycles.
