4-22 Keysight E5260/E5270 User’s Guide, Edition 6
Front Panel Reference
Setup Menus
MON_ITEM Displays the sub menu that provides the following functions.
• ITEM1 Selects the item displayed in the Setup Data 1 area.
• ITEM2 Selects the item displayed in the Setup Data 2 area.
Move the cursor to the function you want to set, and press the
Enter
key. Then the
following message will be displayed.
Monitor Item #: Item
where # is 1 for ITEM1 or 2 for ITEM2, and Item is one of the items listed below.
• OUT Source output setting of the output channel
• CPL Compliance setting of the output channel
• VMR Range value for the voltage measurement
• IMR Range value for the current measurement
• ERR Error code
Press the arrow key to select the item you want to display. Then, press the
Enter
key
to make the setup effective, or press the
Exit
key to cancel changing the setup.
DSPL_FRMT Displays the following message.
Display Format: ENGINEERING or SCIENTIFIC
Press the arrow key to select the data display format, ENGINEERING or
SCIENTIFIC. Then, press the
Enter
key to make the setup effective, or press the
Exit
key to cancel changing the setup.
Display Format Description
ENGINEERING Six-digit numeric value with arithmetic point, and unit.
Example: -123.456pA
SCIENTIFIC Four-digit numeric value with arithmetic point, exponential
part (E, +/− sign, and one- or two-digit numeric value), and
unit.
Example: -1.234E-10A
