4-30 Keysight E5260/E5270 User’s Guide, Edition 6
Front Panel Reference
Setup Menus
Table 4-5 To Perform Diagnostics
Item Description
GPIB For the next message, disconnect the GPIB cable from the GPIB connector. Then, press
the
Enter
key to start diagnostics or the
Exit
key to return to the previous menu.
Open GPIB, then press [Enter].
Press [Exit] to abort
TRIGGER
(BNC)
For the next message, connect the BNC cable between the Ext Trig In and Out connectors.
Then, press the
Enter
key to start diagnostics or the
Exit
key to return to the previous menu.
Connect In to Out, then press [Enter].
Press [Exit] to abort
KEY For the next message, press any front panel key.
DIAG:KEY Press any key.
OK: [Enter] twice or NG: [Exit] twice
Then, the message will be changed as shown below:
DIAG:KEY [label]
OK: [Enter] twice or NG: [Exit] twice
where label must be the name of the key you pressed.
Press another key to continue the key diagnostics. Press the
Enter
key twice if all responses
were good, or press the
Exit
key twice if any response was bad.
HV-LED For the next message, press the
Enter
key if the High Voltage LED is blinking, or press the
Exit
key if the LED does not blink.
DIAG:HV-LED Is the LED blinking?
YES: [Enter] or NO: [Exit]
DGTL-I/O For the next message, disconnect any cable from the digital I/O port. Then, press the
Enter
key to start the diagnostics, or press the
Exit
key to return to the previous menu.
Open DGTL-I/O, then press [Enter].
Press [Exit] to abort
BEEPER For the next message, press the
Enter
key to hear two types of beep sounds every second,
or press the
Exit
key for no beep sounds.
DIAG:BEEP Is beeper making 2 sounds?
YES: [Enter] or NO: [Exit]
