6-28 Keysight E5260/E5270 User’s Guide, Edition 6
Function Details
Initial Settings
Step delay time 0 s WT
Trigger delay time 0 s WT, PT
Trigger mode XE, TV, TI, or GET TM
Trigger port Ext Trig In Start Measurement
trigger input
TGP
Ext Trig Out Measurement
Completion trigger
output
TGP
Digital I/O cleared TGP
Trigger condition of
Start Step Output Setup trigger
with trigger for first sweep step TGSI
Type of output trigger Edge trigger TGXO, TGSO,
TGMO
Digital I/O port Output for all port ERM
Program memory
cleared
a
SCR
Value of internal variable (%In, %Rn) 0 VAR
Data output format ASCII with header, CR/LF^EOI FMT
Data output buffer cleared BC
Status byte Only bit 6 is enabled. *SRE
Error code register cleared ERR?
a. Program memory is not cleared by the *RST command or the device clear.
Setup Item Initial Setting Commands
