Keysight E5260/E5270 User’s Guide, Edition 6 6-29
Function Details
Initial Settings
Table 6-3 Initial Settings
Setup Item Initial Setting Commands
Measurement channel Channel assigned the lowest number. MCH
Measurement data to be displayed Data 1 Compliance side data MPA
Data 2 none MPA
Output channel Channel assigned the lowest number. SCH
Output data to be displayed Data 1 OUT SPA
Data 2 CPL SPA
Data display format ENGINEERING DFM
Remote mode data display off RED
Remote mode key lock/unlock unlock KLC
Auto calibration on CM
ADC zero function (for E5270B) off AZ
SMU output switch open CN, CL
ASU path/1 pA auto range/indicator SMU side/disabled/enabled SAP/SAR/SAL
Filter/Series resistor off/off FL/SSR
A/D converter High speed ADC AAD
Integration time (High resolution
ADC is available for E5270B)
High speed ADC: auto AIT
High resolution ADC: auto AIT
AV command parameter number=1, mode=0 AV
Current measurement range with pulse Compliance range RI
without pulse auto
Voltage measurement range with pulse Compliance range RV
without pulse auto
Sweep source parameters cleared WV, WSV, WI, WSI
Automatic sweep abort function off WM
Output after sweep measurement Start value WM
Pulse source parameters cleared PV, PI
Pulse sweep source parameters cleared PWV, PWI
Pulse width 0.001 s PT
Pulse period 0.01 s PT
Search source parameters cleared BSV, BSSV, BSI, BSSI, LSV, LSSV, LSI, LSSV
Search monitor parameters cleared BGV, BGI, LGV, LGI
Output after search measurement Start value BSM, LSM
Search measurement data Source output value only BSVM, LSVM
Quasi-pulse source parameters cleared BDV
Quasi-pulsed spot measurement mode Voltage BDM
Quasi-pulse settling detection interval Short BDM
Hold time 0 s WT, PT, BDT, BST, LSTM
Delay time 0 s WT, PT, BDT, BST, LSTM
Step delay time 0 s WT
Trigger delay time 0 s WT, PT
Trigger mode XE, TV, TI, or GET TM
Trigger port Ext Trig In Start Measurement trigger input TGP
Ext Trig Out Measurement Completion trigger output TGP
Digital I/O cleared TGP
Trigger condition of
Start Step Output Setup trigger
with trigger for first sweep step TGSI
Type of output trigger Edge trigger TGXO, TGSO, TGMO
Digital I/O port Output for all port ERM
Program memory cleared. Not cleared by *RST command or device clear. SCR
Value of internal variable (%In, %Rn) 0 VAR
Data output format ASCII with header, CR/LF^EOI FMT
Data output buffer cleared BC
Status byte Only bit 6 is enabled. *SRE
Error code register cleared ERR?
