1-4 Keysight E5260/E5270 User’s Guide, Edition 6
Getting Started
Step 1. Turning on the Keysight E5260/E5270
Connect the power cable from the Keysight E5260/E5270 to an AC power outlet,
and press the
Line
switch.
After the self-calibration, the LCD shows the following display:
Step 2. Setting up SMU1, forcing DC voltage, and measuring DC current
1. Press the
CPL Value
key. A cursor appears on the lowest digit of the integral part
of the CPL value. The CPL shows the compliance value.
2. Press the Right arrow key to move the cursor on the arithmetic point.
3. Press the Up arrow key to set the CPL value to 100 mA, and press the
Enter
key
to fix the value. Then press the
Enter
key again. The cursor disappears.
4. Press the
On/Off
key. The SMU1 starts voltage output.
5. Press the
Repeat
key. The SMU1 starts current measurement.
In the following example, the measured data is just an example. During the repeat
measurement, you may not be able to read the measured data.
NOTE The Output indicator shows that DC voltage or current is applied by the channel
specified by the S-ch indicator.
The Repeat indicator shows that the repeat measurement mode is set.
The Meas indicator shows that the measurement channel is performing the
measurement. You will see the indicator if the measurement time is long enough to
display the indicator. Even if the channel performs repeat measurement, you will not
see the indicator if the time to measure one data item is too short to display the
indicator.
Meas Value #1 Meas Value #2 Setting Parameter
Stat
OUT: 0.00 V
CPL: 100.0uA
OFF
Remot e
A 1 1
Shift
Lock
Meas
Trigger
Error
Integ
Re pea t
Ou tpu t
S-ch
M-ch
Meas Value #1 Meas Value #2 Setting Parameter
Stat
OUT: 0.00 V
CPL: 100.0mA
0.00020nA
Remot e
A 1 1
Shift
Lock
Meas
Trigger
Error
Integ
Re pea t
Ou tpu t
S-ch
M-ch
