Keysight Technologies E5260 Series User Manual

2-14 Keysight E5260/E5270 User’s Guide, Edition 6
Introduction
Measurement Modules
Table 2-5 MPSMU Output Voltage Ranges and Resolutions
Table 2-6 MPSMU Output Current Ranges and Resolutions
Range Output Value
Setting
Resolution
Maximum
Current
0.5 V 0 ≤ |V| ≤ 0.5 V
100 μV
a
a. 25 μV for the GPIB remote mode.
± 100 mA
2 V 0 ≤ |V| ≤ 2 V 100 μV ± 100 mA
5 V 0 ≤ |V| ≤ 5 V 250 μV ± 100 mA
20 V 0 ≤ |V| ≤ 20 V 1 mV ± 100 mA
40 V 0 ≤ |V| ≤ 20 V 2 mV ± 100 mA
20 V < |V| ≤ 40 V 2 mV ± 50 mA
100 V 0 ≤ |V| ≤ 20 V 5 mV ± 100 mA
20 V < |V| ≤ 40 V 5 mV ± 50 mA
40 V < |V| ≤ 100 V 5 mV ± 20 mA
Range Output Value
Setting
Resolution
Maximum
Voltage
1 nA 0 ≤ |I| ≤ 1.15 nA 50 fA ± 100 V
10 nA 0 ≤ |I| ≤ 11.5 nA 500 fA ± 100 V
100 nA 0 ≤ |I| ≤ 115 nA 5 pA ± 100 V
1 μA0 ≤ |I| ≤ 1.15 μA 50 pA ± 100 V
10 μA0 ≤ |I| ≤ 11.5 μA 500 pA ± 100 V
100 μA0 ≤ |I| ≤ 115 μA 5 nA ± 100 V
1 mA 0 ≤ |I| ≤ 1.15 mA 50 nA ± 100 V
10 mA 0 ≤ |I| ≤ 11.5 mA 500 nA ± 100 V
100 mA 0 ≤
|I| ≤ 20 mA 5 μA ± 100 V
20 mA < |I| ≤ 50 mA 5 μA± 40 V
50 mA < |I| ≤ 100 mA 5 μA± 20 V
