Keysight E5260/E5270 User’s Guide, Edition 6 2-15
Introduction
Measurement Modules
Table 2-7 MPSMU Measurement Voltage Values and Resolutions
Table 2-8 MPSMU Measurement Current Values and Resolutions
Range
Measurement
Value
a
Measurement Resolutions
High Speed ADC High Resolution ADC
0.5 V 0 ≤ |V| ≤ 0.55 V 25 μV0.5 μV
2 V 0 ≤ |V| ≤ 2.2 V 100 μV2 μV
5 V 0 ≤ |V| ≤ 5.5 V 250 μV5 μV
20 V 0 ≤ |V| ≤ 22 V 1 mV 20 μV
40 V 0 ≤ |V| ≤ 44 V 2 mV 40 μV
100 V 0 ≤ |V| ≤ 100 V 5 mV 100 μV
Range
Measurement
Value
a
a. This column is applied to the auto ranging or the limited auto ranging. For
fixed ranging, maximum measurement value is Range column value.
Measurement Resolutions
High Speed ADC High Resolution ADC
1 nA 0 ≤ |I| ≤ 1.15 nA 50 fA 10 fA
10 nA 0 ≤ |I| ≤ 11.5 nA 500 fA 10 fA
100 nA 0 ≤ |I| ≤ 115 nA 5 pA 100 fA
1 μA0 ≤ |I| ≤ 1.15 μA 50 pA 1 pA
10 μA0 ≤ |I| ≤ 11.5 μA 500 pA 10 pA
100 μA0 ≤ |I| ≤ 115 μA 5 nA 100 pA
1 mA 0 ≤ |I| ≤ 1.15 mA 50 nA 1 nA
10 mA 0 ≤ |I| ≤ 11.5 mA 500 nA 10 nA
100 mA 0 ≤ |I| ≤ 100 mA 5 μA 100 nA
