2-22 Keysight E5260/E5270 User’s Guide, Edition 6
Introduction
Measurement Modules
Table 2-15 HPSMU Measurement Voltage Values and Resolutions
Table 2-16 HPSMU Measurement Current Values and Resolutions
Range
Measurement Value
a
Measurement Resolutions
2 V 0 ≤ |V| ≤ 2.2 V 100 μV
20 V 0 ≤ |V| ≤ 22 V 1 mV
40 V 0 ≤ |V| ≤ 44 V 2 mV
100 V 0 ≤ |V| ≤ 110 V 5 mV
200 V 0 ≤ |V| ≤ 200 V 10 mV
Range
Measurement Value
a
a. This column is applied to the auto ranging or the limited auto ranging.
For fixed ranging, maximum measurement value is Range column
value.
Measurement Resolutions
100 nA 0 ≤ |I| ≤ 115 nA 5 pA
1 μA0 ≤ |I| ≤ 1.15 μA50 pA
10 μA0 ≤ |I| ≤ 11.5 μA 500 pA
100 μA0 ≤ |I| ≤ 115 μA5 nA
1 mA 0 ≤ |I| ≤ 1.15 mA 50 nA
10 mA 0 ≤ |I| ≤ 11.5 mA 500 nA
100 mA 0 ≤ |I| ≤ 115 mA 5 μA
1 A 0 ≤ |I| ≤ 1 A 50 μA
