3-2 Keysight E5260/E5270 User’s Guide, Edition 6
Installation
This chapter describes how to install Keysight E5260/E5270 and accessories.
• “Requirements”
• “Inspection and Installation”
• “Installing Accessories”
• “Mounting Connectors”
• “Connecting Measurement Devices”
• “Maintenance”
WARNING To avoid electrical shock and instrument damage, turn the all instruments off
before connecting or disconnecting measurement cable.
Mettez la machine hors tension pour fixer le connecteur ou pour retirer le
connecteur de l’unité centrale.
WARNING This instrument is heavy and requires a two person lift.
Cet instrument est lourd et nécessite deux personnes pour le soulever.
CAUTION Do not grab the fixture cover when lifting the test fixture.
WARNING There are potentially hazardous voltages (± 200 V for HPSMU, and ± 100 V for
MPSMU) present at the Force, Guard, and Sense terminals of this instrument.
To prevent electrical shock, the following safety precautions must be observed
during the use of this instrument.
• Use a three-conductor AC power cable to connect the instrument to an
electrical ground (safety ground).
• If you do not use the 16442A/B test fixture, you must install and connect an
interlock circuit that opens the Interlock terminal when the shielding box
access door is opened.
• If you change the DUT interface, test fixture, prober, and such, connect an
interlock cable to the one actually used.
• Confirm periodically that the interlock function works normally.
• Before touching the connections on the Force, Guard, and Sense terminals
in the test fixture or the shielding box, turn the instrument off and
discharge any capacitors. If you do not turn the instrument off, complete all
of the following items, regardless of the instrument settings.
•Press the
OutCh
and
On/Off
keys to set the module output off.
