Example 3 Create a custom protection that will disable the output if the output voltage moves outside
the window between 23.5 V and 24.5 V.
1. Select the Threshold icon from the Source list to place it onto the work area. Select Voltage, > dir-
ection, and enter a 24.5 level in the Level dropdown list.
2. Select another Threshold icon from the Source list to place it onto the work area. Select Voltage,
< direction, and enter a 23.5 level in the Level dropdown list.
3. Select the OR operator from the Operator list to place it onto the work area.
4. Move the Threshold icons toward the inputs of the Operator icon until the solid yellow connection
lines appear.
5. Select the Protect icon from the Target list to place it onto the work area.
6. Move the Protect icon toward the output of the Operator icon until the solid yellow connection line
appears.
5 Using the Power Assistant Software
196 Keysight N6900/N7900 Series Operating and Service Guide
