Konica Minolta 7045 - Machine Configuration

3-2 Machine Information
Machine Information
Machine Configuration
External Machine
qRADF (Reversing Automatic Document Feeder)
!7Power switch
!8LCD touch screen
!9Control panel
wWork table
eMullti-sheet (smart)
bypass tray
tUpper right side cover
!3Front door
!6Main power switch
!4Left side cover
!5Finisher
yLower right side cover
uADU
iTray 1
!0Tray 3
oTray 2
rKey counter
DB-608
DB-208
!1Tray 4
!0Tray 3
oTray 2
DB-208A
!2Storage
oTray 2
