13 Suction conveyor
Connect the return flow hose to the turbine via hose clamps.
Tip:
If the hoses are difficult to connect moisten them with water.
Do not use grease!
Mount the conveyor hose (return flow hose)
Connect the pellet hose to the tank cover.
Install the conveyor hose (supply hose)
Place the suction turbine hood on the tank cover and bolt it on tightly.
Install the suction turbine hood
13.4 Final inspection
Ensure that ALL components and connections are correctly installed!
To conclude, ensure that the conveyor system is free of foreign objects!
