KWB Easyfire Installation And Maintenance Manual

© KWB – Kraft und Wärme aus Biomasse GmbH IM Easyfire 10/2008 Page 169
18.2 Hydraulic diagrams
18.2 Hydraulic diagrams
Base module with weather-sensitive control system,
combination load-balancing tank
MBEH0004_a sheet 2/2
System description:
The hydraulic system consists of the boiler circuit, the distributor, and a combination buffer that is switched as load
compensator (VAR 1) in the bypass. The return flow boost is executed via a thermal valve on at least 50 °C. The
basic module for boiler / DHWC & buffer control is equipped with a weather-sensitive control system for 2 heating
circuits (option). One heating circuit is equipped with an analogue room control unit (option), the second heating
circuit is equipped with a digital room control unit (option) for remote control.
Menu basic settings
Parameters Settings
Return ow boost Thermal valve
Network settings Boiler External 2 Heat to target 2
Power output Heating mode
Boiler dependence Yes
Heating circuit/
heating circuit 0 Room sensor Boiler/0
Outdoor sensor Boiler
Function No
Group no. 0
Heating circuit/
heating circuit 1 Room sensor Boiler/1
Outdoor sensor Boiler
Function Yes
Group no. 0
Heating circuit/
heating circuit 2 Room sensor DRCU 1
Outdoor sensor Boiler
Function Yes
Group no. 0
Buer/Buer 0 Function VAR 1
Digital remote control/ Outdoor sensor Boiler
Digital remote control 1 Heating circuit 1 – 2
DHWC 0 – 0
Buer 0 – 0
Hardware Heating circuit modules 0
Digital remote control 1
Plug-in modules O
Comment: None
Subject to change!
Tech. data sheet: HYD-USP-MBEH0004_a, sheet 2/2, date: 13-07-06 StHo
MA-Easyfire 10.2008_EN.indd 169MA-Easyfire 10.2008_EN.indd 169 30.03.2009 13:32:11 Uhr30.03.2009 13:32:11 Uhr

KWB Easyfire Specifications

General

Fuel Type	Wood pellets
Cleaning System	Automatic heat exchanger cleaning
Emission Class	5
Nominal Heat Output	10 kW
Type	Pellet heating system
Ash Removal	Automatic
Heating capacity	10 kW
Hopper capacity	15 kg
Flue diameter	130 mm
