9.10 Fabric tank scope of delivery
Fabric sack
Base plate
for vertical support
Vertical support Horizontal support
Braces A-Storz fill coupling
Fill unit
with hose clamps
90 - 110 mm
Bolts M10 x 35
Clamp, fill coupling Bolts M10 x 25
Bolts M10 x 80 Nuts M10
Shims, M10 Nylon plug 12
Frame boltM10 x 80
