Client: Construction project:
Altitude above sea level: m
Boiler data:
Make: KWB Type: Year of manufacture: Fuel:
Joining piece data:
Material: Sheet steel Stainless steel Other: Insulation thickness: mm
Diameter (Dv):
mm Effective length (Lv): m Effective height (Hv): m
Wall thickness (Sv):
mm Redirectors (z) x 45° x 90° x °
Chimney flue data:
Make/type: Flue installation Flue of pre-assembled pieces Flue gas line Other
Form: Round Rectangular Clear width: x mm Position: In the building On the building Free-standing
Offset: No Yes horizontal , vertical m
Eff. length:
m Connection: T-45° T-90°
Eff. height (Hw): , Cold area (Hk): , Free (Hf): m
Head cladding:
No Yes material Thickness mm
Roof cowl:
No Yes distance (Ad): m
Thermal resistance group:
II III
Structure: Layer thickness 1
mm material
Layer thickness 2 mm material
Layer thickness 3 mm material
Secondary air fixture: No Yes
In the flue In the joining piece
Existing chimney prior to reconstruction:
Form: Round Rectangular Clear width: x mm
Structure: Layer thickness 1
mm material
Layer thickness 2 mm material
Layer thickness 3 mm material
For the correctness of the data:
Place, date:
Signature:
