9 Fabric tank
9.9 Filling instructions (see also the posted information in the storage room and the last page
of this manual)
9.9.1 Prior to filling
Strictly ensure that you switch off the heating system via the control system before
filling the fabric tank!
Comply with the following points before filling:
• When filling the KWB fabric tank it is not necessary to extract the blow-in air and thus an extraction process
is not required. The blow-in air escapes through the fabric of the fabric tank.
• However the set-up room for the fabric tank must have a window, door or a vent opening with at least
170 cm².
• It is not necessary to seal the emergency gate for the removal unit.If the removal unit is missing the included
emergency gate must be pushed in.
• Ensure that all openings on the fabric tank that are not fitted with a fill unit are sealed air-tight.
• Ensure that the fill nozzle is mounted in such a manner that the adjustment angle cannot be changed during
the fill process.
• The holder of the blow-in nozzle is fitted with an earth connection. Ensure that all parts of the fill system are
connected together so that they are conductive!
The incline and setting of the fill nozzle is adjusted when the fabric tank is installed and it depends on the room
height or the set-up variant.
1.) Fill nozzle engaged in the stop bolt
The angle of incline of the fill nozzle is permanently set.
2.) Fill nozzle installed horizontally
The M10 screw with M10 lock nut must be firmly tightened so that adjustment is impossible.
Check the fill angle before filling!
The fill nozzle ( blow-in nozzle) should not touch the storage room ceiling.
The pellets should not be blown on the storage room ceiling
.
