2 System installation
Transfer the screws of the side cladding elements from the front
to the rear.
Transfer screws (1)
Transfer the following screws into the adjacent pressed-in nuts:
Screws for the burner cover
or
screws for fastening the suction tank
Transfer screws (2)
Assemble the boiler in the reverse sequence of steps 2.1.1.1 and 2.1.1.2.
