Synergy Software
Laborie NXT Pro Owner’s Manual LBL-00146 [C], MAN2010 65
To proceed through the workflow steps and their phases, use the icons described in Table 6.
Icon Button Description
Next
Allows the user to proceed to the next phase of the
study. During a urodynamic study, the Next icon will be
accompanied by the title of the next study phase.
Pause
Allows the user to pause the study.
Resume
Allows the user to resume the study.
Close Allows the user to close the phase window.
Table 6: Synergy Navigation Icons
Procedure—Preview Phase
When a study is started, the Preview phase begins the Procedure workflow step. This
phase facilitates all patient setup activities.
4.5.1.1 Slide Sidebar
The slide sidebar provides access to patient, device, and quality process information
throughout the study, using quick access icons. Table 7 provides an overview of each icon’s
functionality.
Slide Sidebar Icon Button Description
Patients
Displays the Patients section.
Patient Details
Displays the Patient Details.
History
Displays the Patient History.
Consumable
Traceability
Displays the Consumable Traceability panel. For more
information on consumable traceability, refer to the
section Consumable Traceability on page 65
.
Quality Control
Check
Displays the Quality Control Check section, which lists
the modules, module statuses, and tasks that must be
completed throughout the study. For more information,
refer to the section UDS Intelligence on page 75
.
Quick Results and
Nomograms
Displays Quick Results and Nomograms for reference
throughout the study. For more information, refer to the
section Quick Results and Nomograms on page 71
Video Panel
Displays live video feed, saved images, recorded video,
brightness slider, and contrast slider. The Video Panel
is available only if Video Settings are turned on in the
workflow of the study under Global Settings.
Table 7: Slide Sidebar Icon Overview
