Synergy Software
Laborie NXT Pro Owner’s Manual LBL-00146 [C], MAN2010 75
While in the Review window, you can do the following:
Access, edit, and review content in the Slide Side Bar.
• Review UDS Intelligence Score, saved video/images in the Video Panel, and
Quick Results.
• Edit patient details and patient history.
• Select images for inclusion in the report.
• Edit Study Configuration settings using the Review Editor available under the
Settings icon. Limited settings are available in the review phase.
Review and edit information in the Graph section.
• Use the red marker to move, add, or delete events in the graph. To move a
marker, click on a marker and drag it to a new position. To insert an event
marker, right-click the location where a marker is required and then, from the
context menu that opens, select the Marker Type. To remove an event marker
from the graph, right-click the event marker and then select Delete Marker.
NOTE: Fixed events such as pump and video/image event markers cannot be moved or
deleted from the graph.
• Move the pointer over video markers to view burst images in the graph. On the
pop-out display window, use the arrows to navigate through images captured
during the study.
• Use the vertical red marker to zoom in on a specific portion of the graph. Click
and drag the red marker to select the portion of the graph to expand. Use the
Previous Zoom button in the control panel to return to the previous
magnification or click Zoom 100% to view the full graph.
• Move the phase boundaries in the graph. Phase boundaries are markers that
show where each phase of the test started and ended. To move the phase
boundaries, do the following:
a) On your keyboard, press Ctrl + Shift. This will cause the Review window to
display in half intensity.
b) Move the vertical red marker to the phase boundary line, click and drag the
phase boundary line to the desired location on the graph.
c) Verify that all changes are saved.
After the review of the study is complete and changes are saved, click the Close button to
return to the main window. Alternatively, click the Report button to load the Report
window beside the Review window in split screen. To exit the review section of the split
screen, click the Close button. To exit the report section of the split screen, click Finish.
4.6 UDS Intelligence
Quality Control (QC)
The UDS Intelligence capabilities within Synergy allow the software to provide feedback on
user adherence to required standards and procedures throughout the study.
You can access the Quality Control window by selecting the Quality Control icon ( ) on
the Slide Sidebar at any time during the study. The quality feedback provided in the
Quality Control window will vary based on the workflow step.
