Labrie EXPERT Service Manual

General Maintenance 117
Figure 3-147 Installing wear pads
11 c. Install the sliding shoe (see Figure 3-148).
Figure 3-148 Installing sliding shoe
11 d. Place the 2 remaining wear pads (one in each section of the rail).
This will keep the sliding shoe in place.
Figure 3-149 Wear pads
11 e. Install the exterior guide and tighten all 14 bolts.
