General Maintenance 141
Figure 3-188
Anti-spill guard
7. Enter the hopper and proceed with the removal of both floating panels (see Figure 3-189).
Figure 3-189
Floating panels
To remove the right-hand side floating panel: a) open the panel, b) slide it to the right and c) lift
it up (see Figure 3-190).
To remove the left-hand side floating panel: a) open the panel, b) slide it to the left and c) lift it
up.
Warning!
Beware of the floating panel pinch points. Keep your fingers and hands away from them.
