146 General Maintenance
Figure 3-197 R-pin holding anti-spill guard in place
8. Remove the hopper divider (see Figure 3-198).
There are 6 bolts that hold the divider to the packer panel. These bolts are to be taken out to
remove the hopper divider. A 5/8” nut located at the rear end of the divider must also be taken
out (see Figure 3-200).
Figure 3-198 Hopper divider
Figure 3-199 Bolts holding divider (6)
