154 General Maintenance
Figure 3-213
Flashing light removed
NEXT: REPLACING AND ADJUSTING UPPER WEAR PADS: see Replacing and Adjusting
Upper Wear Pads on page 163.
D. Co-Mingle Units W/O Loading Arm
Make sure you go through the following steps:
1. Start the engine and engage the hydraulic pump.
2. Fully retract the packer.
3. Turn OFF the hydraulic pump and the engine.
4. Lock out and tag out the vehicle (see Locking Out and Tagging Out the Vehicle on page 14).
5. Open the left/right hand side hopper door.
6. Remove the anti-spill guards located on each side of the hopper (see Figure 3-214).
An R-pin located just behind the anti-spill guard (see Figure 3-215) must be pulled completely to
allow for the removal of the guard.
Figure 3-214
Anti-spill guards
Danger!
Do not enter the hopper while the packer is moving.
