172 General Maintenance
There are 6 bolts that hold the divider to the packer panel. These bolts are to be taken out to
remove the hopper divider. A 5/8” nut located at the rear end of the divider must also be taken
out (see Figure 3-246).
Figure 3-244 Hopper divider
Figure 3-245 Bolts holding divider (6)
Figure 3-246 5/8” nut
8. Remove the divider guard.
4 bolts are to be taken out to remove the divider guard (2 on each end).
