Labrie EXPERT Service Manual

General Maintenance 171
2. Using the joystick, extend the automated arm to get better access to the hopper area.
3. Fully retract the packer using the yellow button on the packer control station.
4. Turn OFF the hydraulic pump and the engine.
5. Lock out and tag out the vehicle (see Locking Out and Tagging Out the Vehicle on page 14).
6. Remove the anti-spill guards located on each side of the hopper (see Figure 3-242).
An R-pin located just behind the anti-spill guard (see Figure 3-243) must be pulled completely to
allow for the removal of the guard.
Figure 3-242 Anti-spill guard
Figure 3-243 R-pin holding anti-spill guard in place
7. Remove the hopper divider (see Figure 3-244).
Danger!
Secure the area around the path of the automated arm when performing maintenance
or repair.
Danger!
Do not enter the hopper while the packer is moving.
