186 General Maintenance
Figure 3-268
Bolts holding divider (6)
Figure 3-269
5/8” nut
7. Remove the divider guard.
4 bolts are to be taken out to remove the divider guard (2 on each end).
Figure 3-270
Divider guard
8. Remove the chute (see Step 10 on page 147 for the chute removing procedure).
9. Once the chute has been removed, start the engine and engage the hydraulic pump.
