General Maintenance 63
Figure 3-50
R-pin holding anti-spill guard in place
2. Remove the hopper divider (see Figure 3-51).
There are 6 bolts that hold the divider to the packer panel. These bolts are to be taken out to
remove the hopper divider. A 5/8” nut located at the rear end of the divider must also be taken
out (see Figure 3-53).
Figure 3-51
Hopper divider
Figure 3-52
Bolts holding divider (6)
