88 General Maintenance
Figure 3-100
Marking down arm stopper location
2. Remove both side panels (one on each side of the hopper).
NOTE: If a tipper is installed on the side panel, you will have first to remove it before removing the side
panel.
Figure 3-101
Side panel
3. Remove the lower part of both side rails (one on each side of the hopper) by using a 5/16-inch
Allen wrench and a 3/4-inch wrench (see Figure 3-194).
There are 6 bolts in total on each side.
NOTE: In order to get access to the last of the 6 bolts that hold the lower part of the side rail in place,
remove the midway flashing lights located on each side of the truck.
