Front view with eight 2.5-inch front drive bays (model 1)
Figure 4. Front view with eight 2.5-inch front drive bays (model 1)
Table 4. Components on the front of the server
Callout Callout
1 “External diagnostics connector” on page 37
2 “VGA connector (optional)” on page 51
3 “Drive activity LED” on page 50 4 “Drive status LED” on page 50
5 Drive bay fillers (2) 6 “Front I/O assembly (on rack latch)” on page 27
7 Rack latch (right)
8 “Pull-out information tab” on page 1
9 Drive bays (8) 10 Rack latch (left)
18 ThinkSystem SR650 V2Maintenance Manual
