Front view with twelve 3.5-inch front drive bays
Table 11. Components on the front of server models
Callout Callout
1 “External diagnostics connector” on page 37
2 “VGA connector (optional)” on page 51
3 “Drive activity LED” on page 50 4 “Drive status LED” on page 50
5 “Front I/O assembly (on rack latch)” on page 27 6 Rack latch (right)
7 “Pull-out information tab” on page 1
8 Drive bays (12)
9 Rack latch (left)
Chapter 2. Server components 25
