Configuration
8200SHB01997-62
7.6 Display functions
7.6.1 Display values
Code Name
Possible settings
IMPORTANT
C
o
d
e
N
a
m
e
Lenze Choice Info
I
M
P
O
R
T
A
N
T
C040 Controller enable * -0- Controller inhibited
-1- Controller enabled
HVAC only *see Operating
Instructions 2102
C046 Frequency setpoint * -480.00 {0.02 %} 480.00 [Hz]
HVAC only
C047* Current setpoint
I
max
limit value
[%]
HVAC only
Display only
150 %for rated value
at term. 8 and factory
setting
C049* Additional setpoint [Hz]
HVAC only
Display only
- Only if C005 = -1-,
-2-
C050* Output frequency [Hz] Display only
C051* Actual PIDcontroller
value
[Hz]
HVAC only
Display only
C052* Motor voltage [V] Display only
C053* DC-bus voltage [V]
HVAC only
Display only
C054* Motor current [A] Display only
C056* Unit load [%] Display only
C061* Temperature
Heat sink
[°C] Display only
Function Some parameters, which are measured by the controller during operation, can be displayed on the
8201BB operating module.
Important
Series “HVAC”:
- Display under C050 corresponds to the setpoint without slip compensation (C021).
- Display under C047:
- If C005 = -0-, -1-, -2-, -6-, -7-,  I
max
limit value (C022).
- Display under C049, only if C005 = -1- and -2-.
Special features
821X/822X/824
Series “HVAC”:
- The display value of a parameter can be related to an application datum(see chapter 7.6.3).
- Codes C046, C049, C050, C051:
Hz display only in factory setting (C500 = 2000; C501 = 10)
(see chapter 7.6.3).
7.6.2 Switch-on display
Code Name
Possible settings
IMPORTANT
C
o
d
e
N
a
m
e
Lenze Choice Info
I
M
P
O
R
T
A
N
T
C004¤ Switch-on display -0- -0- Field frequency f
d
(C050)
-1- Unit load (C056)
-2- Motor current (C054)
Function The here selected display is active after mains connection, if the 8201BB operating module is
plugged on.
