Lenze 8200 - Page 207

Configuration
8200SHB0199
7-69
7.7.2 Analog output
Code Name
Possible settings
IMPORTANT
Lenze Choice Info
C108* Gain (C111) 128 0 {1} 255
C111¤ Monitor signal -0-
-0- Field frequency
-1- Unit load
-2- Motor current
-3- DC bus voltage
-4- Motor power
-5- Motor voltage
-6- Analog output 1/f
d
(1/C050)
-7- Field frequency of
f
dmin
(C010)... f
dmax
(C011)
-8- Actual PID controller value
HVAC only
HVAC only
HVAC only
HVAC only
HVAC only
-9- Ready for operation
-10- TRIP fault message
-11- Motor is running
-12- Motor is running / CW rotation
-13- Motor is running / CCW rotation
-14- Field frequency f
d
=0
-15- f
dset
reached
-16- Q
min
reached
-17- I
max
reached
-18- Overtemperature (Ô
max
-10)
-19- TRIP, Q
min
or IMP set
HVAC only
HVAC only
HVAC only
HVAC only
HVAC only
HVAC only
HVAC only
HVAC only
HVAC only
HVAC only
HVAC only
822X/824X -20- PTC warning HVAC only
-21- Apparent motor current
(C054)< current threshold (C156)
-22- Apparent motor current
(C054)< current threshold (C156)
and f
d
>Q
min
threshold
-23- Apparent motor current
(C054)< threshold (C156)and
input of ramp function generator =
output of ramp function generator
HVAC only
HVAC only
HVAC only
822X/824X -24- Warning motor phase failure HVAC only
-25- f
d
(C050)< f
dmin
(C010) HVAC only
Function
Series “HVAC”:
- To monitor the drive, you can output different process value as standardised voltage via
terminal 62.
- With C111 = -0-, C108 = 0 ... 225 corresponds toan output voltage of 0 V ... 10 V
(at f
d
= C011).
- With C111, C108 = 128 corresponds to an output voltage of 6 V(factorysetting).
- If C111 = -6-, the analog output is reciprocal to the field frequency of the motor. This function can
for instance be used for the external display of a cycle time
- of a product or
- through a furnace.
