Lenze 8200 - Page 216

Configuration
8200SHB01997-78
Code IMPORTANTPossible settingsNameCode IMPORTANT
InfoChoiceLenze
Name
[C007]* Te r mi n a l
configuration
-0- E4 E3 E2 E1
-0- CW/CCW GSB JOG1/2/3
-1- CW/CCW PAR JOG1/2/3
-2- CW/CCW QSP JOG1/2/3
-3- CW/CCW PAR GSB JOG1
-4- CW/CCW QSP PAR JOG1
-5- CW/CCW GSB TRIP set JOG1
-6- CW/CCW PAR TRIP set JOG1
-7- CW/CCW PAR GSB TRIP set
-8- CW/CCW QSP PAR TRIP set
-9- CW/CCW QSP TRIP set JOG1
-10- CW/CCWTRIP set UP DOWN
-11- CW/CCW GSB UP DOWN
-12- CW/CCW PAR UP DOWN
-13- CW/CCW QSP UP DOWN
-14- CCW/QSPCW/QSP GSB JOG1
-15- CCW/QSPCW/QSP PAR JOG1
-16- CCW/QSPCW/QSP JOG1/2/3
-17- CCW/QSPCW/QSP PAR GSB
-18- CCW/QSPCW/QSP PAR TRIP set
-19- CCW/QSPCW/QSP GSB TRIP set
-20- CCW/QSPCW/QSPTRIP set JOG1
-21- CCW/QSPCW/QSP UP DOWN
-22- CCW/QSPCW/QSP UP JOG1
Page 7-10,
7-44, 7-46,
7-50, 7-54,
7-58,
- R=
CWrotation
- L=
CCWrotation
- GSB =
DC-injection brake
- PAR =
Parameter set
changeover
- JOG =
Fixed frequency
- QSP =
Quick stop
- TRIP Set =
External fault
- UP/ DOWN =
Motor potentiometer
functions
For parameter set
changeover via
terminals, the
corresponding terminal
must be assigned with
PARin both parameter
sets.
C008¤ Function relay K1 -1- -0- Readyfor operation
-1- TRIP fault message
-2- Motor is running
-3- Motor is running / CW rotation
-4- Motor is running / CCW rotation
-5- Field frequency f
d
=0
-6- f
dset
reached
-7- Q
min
reached
-8- I
max
reached
-9- Overtemperature (J
max
-10 C)
-10- TRIP or Q
min
or IMP
Page 7-65
C009*¤ Device address 1 1 {1} 99 Only for LECOM
applications
C010 Minimum field
frequency
Page 7-15
820X 0.00 0.00 {0.05 Hz} 480.00
821X/822X/
824X
0.00 0.00 {0.02 Hz} 480.00
C011 Maximum field
frequency
Page 7-15
820X 50.00 30.00 {0.05 Hz} 480.00
821X/822X/
824X
50.00 7.50 {0.02 Hz} 480.00
C012 Acceleration time T
ir
Page 7-16
820X 5.00 0.00 {0.05 s} 999.00
821X/822X/
824X
5.00 0.00 {0.02 s} 999.00
