Code IMPORTANTPossible settingsNameCode IMPORTANT
InfoChoiceLenze
Name
C013 Deceleration time T
if
Page 7-16,
7-55
820X 5.00 0.00 {0.05 s} 999.00
821X/822X/
824X
5.00 0.00 {0.02 s} 999.00
C014¤ Control mode Page 7-19,
7-22, 7-24
820X -0- -0- Linear characteristic Vf
d
with
auto boost
-1- Square characteristic Vf
d
2
with
auto boost
-2- Linear characteristic Vf
d
with
constant V
min
boost
-3- Square characteristic Vf
d
2
with
constant V
min
boost
821X/822X/
824X
-4- -4- Motor-current control
C015
V/f-rated frequency Page 7-22
C
0
1
5
820X 50.00 30.00 {0.05 Hz} 960.00
821X/822X/
824X
50.00 7.50 {0.02 Hz} 960.00
C016
V
min
setting Page 7-24
C
0
1
6
820X * 0.00 {0.02 %} 40.00 *depends on the unit
821X/822X/
824X
0.00 0.00 {0.02 %} 40.00
C017 Threshold Q
min
0.00 0.00 {0.02 Hz} 480.00 Page 7-65
C018¤
Chopper frequency Page 7-29
C
0
1
8
¤
821X/822X/824X -1- -0- 4 kHz power-loss optimised
-1- 8 kHz power-loss optimised
-2- 12 kHz power-loss optimised
-3- 16 kHz power-loss optimised
-4- 12 kHz noise optimised
-5- 16 kHz noise optimised
C019
Threshold
auto DC brake
Page 7-56
821X/822X/824X 0.10 0.10 {0.02 Hz} 5.00
C021
Slip compensation Page 7-28 * If C014 = -2-, -3-,
controller dependent
820X 0.0* 0.0 {0.1 %} 12.0
821X/822X/
824X
0.0* 0.0 {0.1 %} 20.0
C022 I
max
limit
(motor mode)
150 30 {1 %} 150 Page 7-17
C023
I
max
limit
(generator mode)
80 30 {1 %} 110 Page 7-17
The current-limit
controller for operation
i
n
g
e
n
e
r
a
t
o
r
m
o
d
e
i
s
822X/824X 80 30 {1 %} 150 As of software
1.6
c
o
n
t
r
o
l
l
e
r
f
o
r
o
p
e
r
a
t
i
o
n
in generator mode is
notactiveat30%.
C034¤ Master current -0- -0- 0 to 20 mA /
0to5V/0to10V
-1- 4 to20 mA
Page 7-40
