Lenze 8200 - Page 219

Configuration
8200SHB0199
7-81
Code IMPORTANTPossible settingsNameCode IMPORTANT
InfoChoiceLenze
Name
C117¤ Function relay K2
822X/824X
-0- -0- Ready for operation
-1- TRIP fault message
-2- Motor is running
-3- Motor is running / CW rotation
-4- Motor is running / CCW rotation
-5- Field frequency f
d
=0
-6- f
dset
reached
-7- Q
min
reached
-8- I
max
reached
-9- Overtemperature (J
max
-10C)
-10- TRIP or Q
min
or IMP
-11- PTC warning
Page 7-65 ff
C119¤ Function PTC
822X/824X
-0- -0- PTC input not active
-1- PTC input active, TRIP and pulse
inhibit will be set
-2- PTC input active
Wa rni ng
Page 7-72
C120
I
2
ktswitch-off Page 7-71
C
1
2
0
822X/824X 0 0 {1 %} 100 If C120 = 0, the
function is not active
C125¤* LECOMbaud rate -0- -0- 9600 baud
-1- 4800 baud
-2- 2400 baud
-3- 1200 baud
-4- 19200 baud
Only for LECOM
applications
C142¤ Start condition -1- -0- Automatic start inhibited,
flying-restart circuit not active
-1- Automatic start, if term. 28 HIGH,
flying-restart circuit not active
-2- Automatic start inhibited,
flying-restart circuit active
-3- Automatic start, if term. 28 HIGH,
flying-restart circuit active
Page 7-49
C144¤
Chopper-frequency
reduction
Page 7-29
821X/822X/824X -1- -0- No chopper-frequency lowering
-1- Automatic chopper frequency
reduction at J
max
-10C
C161* Current fault Page 8-2
C162* Last fault Page 8-2
D
i
s
p
l
a
y
o
n
l
y
C163* Last but one fault Page 8-2
D
i
s
p
l
a
y
o
n
l
y
C164* Last but two fault Page 8-2
C170¤ TRIP-reset selection -0- TRIP reset by pressing the STP key
or LOW signal at ctrl. enable or
fieldbus
-1- Auto TRIP reset or TRIP reset by
pressing the STP key or LOW signal
at ctrl. enable or fieldbus
Page 8-4
C171 Deceleration for
Auto-TRIP reset
0.00 0.00 {0.01 s} 60.00 Page 8-4
C178* Operating time Page 7-64 Display only
